The Finale: Energy in the Real World, and the Complete Formula Card

5 min read · 918 words

JEE/NEET Physics · Work, Energy & Power series · Part 8 of 8 · All parts →

Variable Forces: The Graph Trick
Energy Curves: Reading Stability
The Human Engine
The Energy Economy
Solved Examples
This Physics in Your Daily Life
Practice set (answers hidden — try first)

✪ Key points — the 30-second version

Variable forces: work = area under the force-distance graph
Energy curves: valleys = stability, hills = instability
Rockets, humans, engines: everyone obeys the same energy ledger
Efficiency chains explain the entire energy economy
Complete chapter formula card at the end

A rocket burns tonnes of fuel, your body runs a marathon on a plate of rice, a dam lights a city — three systems, one ledger. The finale of the Work, Energy & Power series handles the advanced leftovers and hands you the complete formula card.

In this card

Variable forces: the graph trick
Energy curves: reading stability
The human engine
The energy economy
Solved examples
Common mistakes
This physics in your daily life
Practice set
Recap + formula card

Variable Forces: The Graph Trick

W = Fd assumed constant force. When the force changes (springs! air drag!), plot force vs distance — the work is the area under the graph. Spring work ½kx² is exactly the triangle under F = kx: ½ × base × height = ½ × x × kx. One picture unifies every variable-force case.

Energy Curves: Reading Stability

Plot a body’s PE against position. Valleys = stable equilibrium (pushed away, it rolls back — a ball in a bowl). Hills = unstable (a pencil on its tip — any nudge and it leaves). Flat = neutral (a ball on a table). And a small wiggle at a valley’s bottom is automatically simple harmonic motion — the bridge into the next series, Oscillations.

The Human Engine

Your body runs at ~100 W idle, ~400 W walking, ~1,000 W sprinting (elite cyclists touch 1,500 W bursts). A day’s food ~9 MJ — roughly a 100 W bulb burning 24 hours. You are, quite literally, a moderately powerful heat engine with excellent snack logistics.

The Energy Economy

Chemical (fuel/food) → heat → motion/electricity, with losses at every step. A power plant: fuel → steam → turbine → electricity ≈ 40% max; an EV battery-to-wheel ≈ 85%; incandescent bulb: 5% light, 95% heat. Every ‘energy crisis’ discussion and star-rating sticker is this chapter at civic scale.

Solved Examples

✎ Easy — graph work. A force grows linearly from 0 to 50 N over 4 m. Work?

Area under the line = triangle = ½ × 4 × 50 = 100 J.

Cross-check: average force 25 N × 4 m = 100 J ✔

Answer: 100 J

✎ Exam level — curve reading. A PE curve has a valley at x = 2 m. At the valley floor, the force on the body is:

Force = the curve’s slope — at a valley’s floor, slope = 0 → zero force (equilibrium), and displaced either way, the slope pushes it back — that’s stability. ✔

Answer: zero force; stable — it returns

✎ JEE level — full chain. A 60% efficient motor pumps 5,000 kg of water up 12 m each minute (g = 10). Electric power drawn?

Useful: mgh/t = 5,000×10×12 ÷ 60 = 10,000 W.

Drawn: 10,000 ÷ 0.6 ≈ 16.7 kW.

The 6.7 kW gap = motor heat — efficiency is always a heat story. ✔

Answer: ≈ 16.7 kW

⚠ Mistakes students make — and how to avoid them

Fearing graphs. Work = area under force-distance graph — count squares or use triangle/rectangle shapes; never assume constant force when told it varies.
Valley vs hill confusion. Valley = stable (returns), hill = unstable (leaves). Draw the ball; feel the answer.
Efficiency multiplied wrong direction. Input = useful ÷ efficiency (bigger); output = input × efficiency (smaller). Check with the ‘must be < 100%' rule.
Human power overestimated. A human sustains ~100-150 W, peaks ~1,000+ W. We’re light bulbs, not engines.

This Physics in Your Daily Life

◎ This physics in your daily life

Fuel prices, star ratings, EV debates, climate targets — all public arguments about efficiency chains; this chapter is the literacy behind the headlines.
Your breakfast is a power contract: ~2,000 food-calories ≈ 8.4 MJ ≈ a 100 W machine’s daily supply — you budget energy like any engine.
Mountain roads zigzag because engines (fixed power) trade distance for force on climbs — switchbacks are P = Fv carved into geography.
Bungee cords and climbing ropes are engineered force-distance curves: they stretch to extend stopping distance, softening the force peak — the area under the graph, saving spines.
Grid-scale batteries and pumped lakes buy energy cheap, store it (PE!), sell it dear — the ledger, monetised at national scale.

What	Formula	Remember
Work	W = Fd·cosθ	perpendicular = zero; against motion = negative
Kinetic energy	½mv²	square! double speed ×4
Work-energy theorem	W_total = ΔKE	before/after only — path-free
Height PE	mgh	choose one zero level
Spring PE	½kx²	stretch squared; metres!
Energy conservation	KE + PE = constant (gravity/springs)	friction leak = F·d → heat
Drop speed	v = √(2gh)	no mass anywhere
Loop minimums	v_top = √(gR); v_bottom = √(5gR); h = 2.5R	gravity helps at the top
Power	P = W/t = Fv	watts; 1 hp = 746 W
Efficiency	useful ÷ input	always < 100%
Collisions	momentum always survives	sticking = max KE loss; equal-mass elastic = swap
Variable force	work = area under F-d graph	½kx² is the triangle
PE curves	valley = stable, hill = unstable	slope = force

Practice set (answers hidden — try first)

(NEET-level) Force rises linearly 0→30 N over 6 m. Work:

Triangle: ½ × 6 × 30 = 90 J.

(Concept) A PE curve’s hill-top is what kind of equilibrium:

Unstable — any nudge and the body leaves.

(JEE Main-level) A 75% motor delivers 3 kW useful. Input power:

3 ÷ 0.75 = 4 kW.

(Concept) Why do switchback mountain roads exist?

Fixed engine power: trading distance for climbing force (P = Fv) — geography applying this chapter.

(JEE Main-level) A ball dropped from h on a spring (k): maximum compression x satisfies:

mgh = ½kx² → x = √(2mgh/k).

🧠 Memory tricks & everyday anchors — the 20-second revision

🧠 Graph chant: ‘the area under the force curve IS the work’.
🧠 Three roots to remember: √(2gh) drop, √(gR) loop-top, √(5gR) loop-bottom.
🏠 Daily: you are a ~100 W appliance that runs on rice — the ledger applies to bodies too.
🏠 Daily: every star rating and fuel-price headline is this chapter at civic scale.
🔁 work = area under F-d graph
🔁 valley/hill on PE curve = stable/unstable
🔁 √(2gh), √(gR), √(5gR) — the three famous roots

▶ Recap card — save for revision week
