Projectile Motion: Mastering the Physics of Horizontal Launch
JEE/NEET Physics · Motion in a Plane series · Part 2 of 6 · All parts →
- A horizontally-thrown ball falls EXACTLY as fast as one simply dropped — the horizontal throw changes where, not how fast, it falls
- Two independent movies at once: horizontal = constant velocity, vertical = free fall
- Time of fall depends ONLY on height: t = √(2h/g)
- Horizontal range = u × t = u√(2h/g)
- Velocity at any instant: combine vₓ (constant) and v_y = gt by Pythagoras
Famous thought experiment: fire a bullet horizontally and drop an identical bullet at the same instant — they hit the ground together. The horizontal motion and the vertical fall don’t argue; they simply ignore each other. This single sentence contains the entire physics of horizontal projectiles, and in this part of the Motion in a Plane series we will unpack it completely — with derivations, worked examples, exam traps, and the everyday places this physics quietly operates.
Horizontal launch is the simplest possible projectile: the object starts its flight with velocity purely in the horizontal direction, and gravity does the rest. Master this case and the angled projectile of Part 3 becomes almost mechanical — because every angled launch can be split into a horizontal launch problem plus a vertical throw problem.
- The two-movie trick
- Time of flight from height alone
- Range of the horizontal throw
- Velocity on the way down
- Solved examples
- Common mistakes
- This physics in your daily life
- FAQ
- Practice set
- Recap
The Two-Movie Trick: Independence of Horizontal and Vertical Motion
A ball rolled off a table is starring in two films simultaneously. Horizontal film: no horizontal force acts on it (we neglect air resistance), so by Newton’s first law its horizontal velocity stays constant at u forever. Vertical film: gravity acts downward with acceleration g, so the ball free-falls from rest, covering ½gt² downward in time t. The films never interact — the total motion is just both playing at once, superimposed.
Why can we legitimately add two such different motions? Because displacement, velocity, and acceleration are vectors, and perpendicular vector components obey independent equations. The x-equations of motion (aₓ = 0) and the y-equations of motion (a_y = g) never share a term. Write the kinematics separately for each axis, solve each one-dimensional problem, and recombine the answers by Pythagoras and trigonometry at the end. This independence is the entire secret of projectiles — and it is exactly why Part 1’s vector resolution skills matter here.
A quick sanity check with numbers: a ball launched horizontally at 5 m/s from a 20 m cliff. At t = 1 s it has moved 5 m across (x = 5 × 1) and 5 m down (y = ½ × 10 × 1²). At t = 2 s, 10 m across but 20 m down. The horizontal column grows steadily; the vertical column grows faster and faster. Two different stories, told at the same clock time, about the same ball.
Time of Flight from Height Alone
Watch only the vertical film: the ball starts with zero vertical velocity and falls distance h under gravity. Using h = ½gt² and solving for t:
t = √(2h/g)
Notice what’s missing from this equation: the throw speed. A bullet fired at 1000 m/s and one gently nudged off the same table land at the same MOMENT — the faster one just lands much farther away. Height is the only variable that controls the clock of a horizontal projectile. This is the single most-tested idea from this topic in NEET and JEE papers, so internalize it now: time of flight is a vertical-axis property and is completely blind to u.
Worked micro-check: from h = 5 m (g = 10), t = √(2 × 5/10) = √1 = 1 s. From h = 20 m, the height is 4× larger, so the time is only √4 = 2× larger. Time scales with the square root of height, not with height itself — a favourite proportionality question in exams.
Range of the Horizontal Throw
Now watch only the horizontal film: constant velocity u for the entire flight time t. Distance = speed × time, and since t is already fixed by height:
| Letter | What it means (plain words) | Value / unit |
|---|---|---|
| u | horizontal launch speed (constant all flight) | m/s |
| h | height of the launch point above the floor | m |
| t | time in the air (set by h alone) | s |
| R | horizontal distance travelled before landing | m |
| v_y | downward speed so far: gt | m/s |
Read the range formula like a sentence: range grows linearly with launch speed and with the square root of height. Double the speed → double the range. Quadruple the height → only double the range. These proportionality one-liners let you answer several JEE Main questions in under ten seconds without touching a calculator.
Velocity on the Way Down
At any instant during flight: vₓ = u (never changes — no horizontal force) and v_y = gt (grows steadily from zero). The actual velocity is their vector sum:
v = √(u² + g²t²), at angle θ = tan⁻¹(gt/u) below the horizontal
The velocity vector starts perfectly horizontal at launch and dips steeper and steeper as gt overtakes u. The path traced by the ball — obtained by eliminating t from x = ut and y = ½gt² to get y = gx²/2u² — is a parabola: flat at launch, plunging at the end. That y ∝ x² dependence is the algebraic fingerprint of every projectile path, whether launched horizontally or at an angle.
One beautiful exam shortcut: at landing, v_y = gt = g√(2h/g) = √(2gh) — the same speed a dropped object would have from height h. So the landing speed is √(u² + 2gh): launch-speed contribution and free-fall contribution combined by Pythagoras, exactly as the independence principle demands.
Solved Examples
Vertical film first: t = √(2 × 1.25/10) = √0.25 = 0.5 s.
Horizontal film next: R = 4 × 0.5 = 2 m.
✔ Notice the strategy — vertical axis gives time, horizontal axis spends that time.
Answer: 0.5 s; 2 m
t = √(2 × 20/10) = 2 s, so v_y = gt = 20 m/s at landing. vₓ stays 15 m/s.
Speed = √(15² + 20²) = √625 = 25 m/s, at tan⁻¹(20/15) ≈ 53° below horizontal.
✔ The 15–20–25 triple is the 3-4-5 triangle scaled by 5 — spot these to save time.
Answer: 25 m/s at 53° below horizontal
The package leaves with the drone’s horizontal velocity 40 m/s — it is a horizontal launch, not a straight drop.
t = √(2 × 45/10) = 3 s; package travels 40 × 3 = 120 m forward while falling.
Release 120 m before the target — this is literally how cargo drops and aid deliveries are computed.
✔
Answer: 120 m early
- Thinking a faster horizontal throw stays up longer. Flight time comes from height alone — horizontal speed has zero vote.
- Using the 1-D equation v² = u² + 2as across both axes. Each equation belongs to ONE axis; never mix x quantities into y equations.
- Forgetting vₓ never changes. No horizontal force (air ignored) means the horizontal velocity at landing equals the launch value.
- Treating the path as a straight slanted line. It’s a parabola — flat start, accelerating dip; the steepness grows with time, not distance.
- Adding u and gt arithmetically at landing. Velocity is a vector: combine vₓ and v_y by Pythagoras, and quote the direction (angle below horizontal) too — JEE mark schemes ask for it.
- Assuming a released object ‘drops straight down’ from a moving vehicle. It inherits the vehicle’s horizontal velocity — the drone example, flipped.
This Physics in Your Daily Life
- Basketball passes are aimed above and ahead — your brain runs the two-movie trick: lead the runner (horizontal constancy) while gravity pulls the ball (vertical fall).
- Cargo/aid drops from planes release hundreds of metres before the target: R = u√(2h/g), exactly Part 2’s drone example with lives at stake.
- Water from a horizontally-held hose — the jet’s parabola is this card drawn in water; bend the hose upward and you’re halfway to Part 3.
- Long-jump take-off boards — jumpers fight for height because time aloft (√(2h/g)) is what converts speed into distance.
- Monkey-and-hunter demonstrations — a dart aimed AT a dropped monkey hits it: gravity affects both identically, the classroom classic of independence of motion.
- Motorcycle stunt jumps over ramps — stunt planners use R = u√(2h/g)-style reasoning (extended to angled launches in Part 3) to make sure the landing ramp sits where the parabola lands.
Two channels on one screen: the horizontal channel plays ‘constant speed cruise’, the vertical channel plays ‘free fall’. Neither director watches the other’s film. The ball doesn’t ‘know’ it’s moving sideways as it falls, and doesn’t ‘know’ it’s falling as it cruises. Independence, not cooperation.
Ball off a 45 m cliff at 10 m/s: every 0.5 s it has moved exactly 5 m across (10 × 0.5) while falling 1.25, 5, 11.25 m (½gt²) — the across-column counts evenly, the down-column squares. Read the two columns side by side and you’re reading the parabola’s DNA.
Plot the trail: mark equal horizontal steps (cruise), and at each mark drop by ½gt² (fall). Equal steps with squaring drops trace a parabola — flat at launch, steeper later. One graph, both movies superimposed.
Frequently Asked Questions
Does a horizontally launched projectile have acceleration at the top of its path?
What happens to the trajectory if air resistance is included?
At what angle does the projectile hit the ground?
Can the range formula R = u√(2h/g) be used for any projectile?
Practice set (answers hidden — try first)
(NEET-level) Ball off a 45 m table: flight time (g=10) =
(JEE Main-level) Off a 20 m cliff at 10 m/s: range =
(NEET-level) Doubling horizontal speed from a fixed height:
(Concept) A bullet fired horizontally and one dropped simultaneously from the same height:
(JEE Main-level) vₓ = 12, v_y at landing = 16: landing speed =
(JEE Main-level) Ball leaves a 80 m cliff at 10 m/s. At what angle does it land? (g = 10)
- two independent movies: cruise + fall
- t = √(2h/g) — throw speed has no vote
- R = u√(2h/g)
- vₓ constant forever; v_y = gt
- landing v_y = √(2gh) — same as a free fall from h
- path is a parabola (y ∝ x²)
- 🔁 independence of x and y motion
- 🔁 t = √(2h/g) from height alone
- 🔁 R = u√(2h/g)
Key Takeaways
Before moving to Part 3, make sure these four statements feel obvious rather than memorised. (1) Horizontal and vertical motions are fully independent because gravity has no horizontal component and no force is needed to maintain constant horizontal velocity. (2) Time of flight depends on height alone, t = √(2h/g). (3) Range is simply that time spent at constant horizontal speed, R = u√(2h/g). (4) The velocity at any instant is the vector sum of a constant u and a growing gt, tracing a parabola whose steepness increases with time. Hold onto this framework — the angled projectile ahead is the same two movies with one extra step at the start.
- 🧠 Chant: ‘height sets time, speed sets distance’.
- 🧠 Classic: fired bullet and dropped bullet land together.
- 🧠 Formula pair: t = √(2h/g), R = u√(2h/g).
- 🧠 Vector rule: landing speed = √(u² + 2gh), angle tan⁻¹(√(2gh)/u).
- 🏠 Daily: basketball leads the runner, gravity drops the ball.
- 🏠 Daily: aid planes release early by R = u√(2h/g).
