In one line: Gravitation Bonus — exam-ready notes in one glance.
In one line: JEE/NEET Physics · Gravitation series · Part 9 (bonus) · All parts →✪ Key points — the 30-second versionField intensity E = GM/r² = −dV/dr — force per.
In fact, JEE/NEET Physics · Gravitation series · Part 9 of 9 · All parts →
- Moreover, field = gravity felt per kilogram (E = GM/r²) — exists even in empty space
- Therefore, inside a hollow planet shell: gravity is exactly ZERO everywhere
- Meanwhile, at a planet’s centre: no pull, but the deepest gravity trap
- As a result, weightlessness = falling together, NOT zero gravity
- TV satellites sit at exactly 36,000 km — here’s why
In other words, eight cards covered the main roads. Meanwhile, this bonus card completes the chapter’s side streets — gravity ‘field’, the hollow-shell surprise, true weightlessness. Why your TV satellite sits at exactly 36,000 km. All simple, all exam-tested. Moreover, part 9 (bonus) of the Gravitation series .
- Notably, gravity field: the ‘pull per kilogram’.
- The hollow-planet surprise.
- Indeed, at the centre of a planet.
- Weightlessness, properly understood.
- TV satellites: the 36,000 km story.
- Solved examples.
- Common mistakes.
- Specifically, this physics in your daily life.
- Practice set.
- Recap.
Gravity Field: The ‘Pull Per Kilogram’.
Similarly, you know g = 9.8 m/s². Therefore, generalise: the field at any point is the pull a 1-kg test mass would feel there: E = GM/r², direction: toward the planet. The subtle point: the field exists whether or not anything is there to feel it — it’s a property of space around a mass, an invisible arrow at every point. Meanwhile, (E and g are the same number; exams swap the names.)
The Hollow-Planet Surprise.
Overall, stand anywhere inside a hollow spherical shell of rock. Which way do you fall? As a result, nowhere — gravity is exactly zero, everywhere inside. Not approximately — exactly.
Consequently, look at a patch of shell on your right: close, so it pulls hard. Meanwhile, a cone of vision catches only a small patch. The same cone extended left catches a bigger but farther patch that pulls weakly. Small-near-strong exactly cancels big-far-weak. Every direction cancels. Notably, this is why, when you dig into the Earth ( Part 7 ). Only the rock BENEATH you counts — the shell above you cancels itself out.
At the Centre of a Planet.
Furthermore, combine the ideas: at the centre, pulls cancel from all sides (field = 0. Meanwhile, you’d float) — but the gravity trap is at its deepest (energy −1.5GMm/R). No pull ≠ shallow trap. Specifically, a favourite conceptual MCQ: zero field, deepest well — both at once.
Weightlessness, Properly Understood.
Likewise, astronauts float not because gravity is absent (at ISS height it’s 89% of surface value) but because they and their spacecraft fall together — nothing presses against anything. Meanwhile, same as a lift with a snapped cable: you’d float inside it, in full gravity. Weight is a contact force; weightlessness is absence of contact.
TV Satellites: The 36,000 km Story.
In short, for a satellite to hover over one fixed spot (so your dish never moves), it must circle exactly once per day. Meanwhile, part 3’s rule then FIXES its distance — no choice: r³ = GMT²/4π² gives r ≈ 42,300 km from Earth’s centre, i.e. Plus two more conditions: circle directly above the equator, moving eastward. All three together = ‘geostationary’.
Solved Examples.
Subsequently, direct: E = GM/(2R)² = GM/4R².
Check: double the distance, quarter the field — the same inverse-square as gravity always.
Answer: GM/4R², pointing at the planet
In fact, step 1 — Kepler solved for r: r³ = GMT²/4π² = 6.67×10⁻¹¹ × 6×10²⁴ × (8.64×10⁴)² ÷ 39.5 ≈ 7.55×10²².
Moreover, step 2 — cube root: r ≈ 4.23×10⁷ m.
Therefore, step 3 — minus Earth’s radius: h = 42,300 − 6,400 ≈ 36,000 km.
Meanwhile, you just derived the most famous number in satellite TV.
Answer: h ≈ 36,000 km
- Field vs force. As a result, field (N/kg) exists without a test mass; force (N) needs one. MCQs swap them.
- Consequently, ‘Zero field at the centre = zero trap.’ Zero pull, deepest trap — different questions, different answers.
- ‘Geostationary’ vs ‘geosynchronous’. Geosynchronous: any orbit with a 24-h lap (may swing in a figure-eight). Geostationary: 24-h lap AND over the equator AND circular — parked. NEET tests the vocabulary.
- Weightlessness as ‘no gravity’. 89% of gravity is present at the ISS — the float is shared falling.
This Physics in Your Daily Life.
- Every TV dish on every rooftop points at one invisible point 36. 000 km above the equator — INSAT-class satellites parked there by this card’s maths, photographing weather and beaming channels for two decades.
- Zero-g research on the ISS — crystal growth, protein folding, fluid behaviour — is really ‘shared free fall’ research; pharma companies pay millions for it.
- The 2,000+ satellites in that one narrow ring make it the most valuable real estate in space — slot assignments are internationally regulated. Dead satellites are pushed to a graveyard orbit.
- Gravity-gradient stabilisation: a satellite’s near side feels slightly stronger pull than its far side (field changes with distance!) — enough to keep it pointing at Earth, no fuel needed.
Practice set (answers hidden — try first).
(NEET-level) Field at 3R (surface value E₀):.
(Concept) Inside a hollow spherical shell:.
(Concept) Astronauts float because:.
(NEET-level) A geostationary satellite must have:.
(Concept) At a planet’s centre, weight and gravity trap are:.
- 🧠 Inside a shell = zero gravity, exactly — ‘near-small cancels far-big’, every direction.
- 🧠 GEO number: 36,000 km — ’24-hour lap over the equator’ forces it; no choice.
- 🧠 Weight is contact: floating = falling together, not missing gravity (89% of gravity is present at the ISS).
- 🏠 Daily: every rooftop TV dish points at the 36,000 km parking ring — INSAT satellites have beamed weather and channels from there for decades.
- 🏠 Daily: medicines grown on the ISS — ‘shared free fall’ is a pharma laboratory worth crores.
A field is gravity’s version of a smell: you don’t need to touch the source to know it’s there. Every mass fills space around it with ‘if you were here, you’d fall THIS way’ information. And GEO satellites are the perfect trick: orbit exactly once a day, and you circle at the same speed the Earth spins — parked over one spot forever.
Field strength: Earth’s field is 9.8 N/kg at the surface, but only 0.22 N/kg at GEO height (42,000 km from Earth’s centre). Exactly one strength exists where the orbital period equals 24 hours — and that’s where all TV satellites must live. Inside a shell (Shell Theorem), the field is exactly zero: the walls pull you in all directions at once, cancelling perfectly.
Draw arrows pointing at Earth in every location — a hedgehog of fall-directions. Long arrows near, stubby arrows far. Inside a hollow planet, no arrows at all. A GEO satellite sits where its arrow is just the right length for a 24-hour loop — the only such spot in the sky.
- field E = GM/r² — pull per kilogram; exists in empty space
- inside a hollow shell: gravity exactly zero (near-small cancels far-big)
- planet centre: field zero, trap deepest (−1.5GMm/R)
- weightlessness = shared free fall; weight = contact force
- geostationary = 24-h lap + equator + circle → exactly 36,000 km
Frequently Asked Questions.
What should you know about Gravity Field: The 'Pull Per Kilogram'?
What should you know about The Hollow-Planet Surprise?
Stand anywhere inside a hollow spherical shell of rock. Which way do you fall? Nowhere — gravity is exactly zero, everywhere inside. Not approximately — exactly. Look at a patch of shell on your right: close, so it pulls hard. A cone of vision catches only a small patch. The same cone extended left catches a bigger but farther patch that pulls weakly. Small-near-strong exactly cancels big-far-weak. Every direction cancels. This is why, when you dig into the Earth (Part 7), only the rock BENEATH you counts — the shell above you cancels itself out.
What should you know about At the Centre of a Planet?
What should you know about Weightlessness, Properly Understood?
What should you know about TV Satellites: The 36,000 km Story?
For a satellite to hover over one fixed spot (so your dish never moves), it must circle exactly once per day. Part 3’s rule then FIXES its distance — no choice: r³ = GMT²/4π² gives r ≈ 42,300 km from Earth’s centre, i.e. Plus two more conditions: circle directly above the equator, moving eastward. All three together = ‘geostationary’.
