- A bar magnet has two poles that always come in pairs — cut one, get two magnets, never a lone pole
- Magnetic dipole moment: m = M × 2ℓ (pole strength × length), pointing S → N
- A current loop IS a magnetic dipole: m = NIA — magnets are hidden currents
- Field lines run outside N → S, inside S → N: closed loops, no start or end
- No magnetic monopoles have ever been found — the deepest asymmetry with electricity
Cut a magnet in half and you don’t get a separate north and south — you get two smaller magnets. Poles come in inseparable pairs, and that single fact shapes everything about how magnetism behaves in matter. Part 1 of the Magnetism & Matter series.
- The uncuttable pair
- Dipole moment: the strength arrow
- A loop is a magnet
- Field lines’ closed loops
- Solved examples
- Common mistakes
- This physics in your daily life
- Practice set
- Recap
The Uncuttable Pair
Electric charges come solo (+ or − alone). Magnetic poles never do: every magnet, however finely divided, keeps both poles. Slice to atomic size and each atom is still a tiny N-S pair. Magnetism is inherently dipolar.
Dipole Moment: The Strength Arrow
| Letter | What it means (plain words) | Value / unit |
|---|---|---|
| m | magnetic dipole moment — strength and direction | A·m², from S pole to N pole |
| M | pole strength | A·m (weber/m in older texts) |
| 2ℓ | separation between the poles | m |
| N, I, A | loop’s turns, current, area | m = NIA |
A Loop Is a Magnet
A current loop’s field at a distance is indistinguishable from a bar magnet’s: the loop IS a dipole with m = NIA. The everyday bar magnet works because trillions of atomic current loops (electron orbits and spins) align — magnets are hidden circulating currents, as Ampere first guessed.
Field Lines’ Closed Loops
Outside a magnet, lines run N → S; inside, S → N: every line closes on itself. Unlike electric field lines (which start on + and end on −), magnetic lines have no beginning or end — the geometric signature of ‘no monopoles’.
Solved Examples
m = NIA = 100 × 2 × 10×10⁻⁴ = 0.2 A·m².
✔
Answer: 0.2 A·m²
Each half keeps the same pole strength M but half the length: m/2 each — and both halves remain full dipoles.
✔
Answer: m/2 each
Solenoid: m = 500×0.5×20×10⁻⁴ = 0.5 A·m². Bar: m = 1×0.05 = 0.05 A·m².
The solenoid outmuscles the small bar magnet 10:1 — coils are strong magnets wearing copper clothes.
✔
Answer: 0.5 vs 0.05 A·m²
- Isolating a pole by cutting. Impossible — every fragment keeps both poles: monopoles don’t exist.
- m’s direction reversed. Moment points S → N (inside the magnet), opposite to the outside field lines.
- Confusing pole strength M with moment m. Moment = M × length: a long weak magnet can match a short strong one.
- Electric dipole formula creep. Magnetic dipoles have their own field expressions (axial: μ₀2m/4πr³) — don’t transplant 1/4πε₀ formulas.
This Physics in Your Daily Life
- Fridge magnets and compass needles — engineered dipole moments: strength quoted (in gauss) is really about m.
- Refrigerator-door magnet sheets — flexible arrays of dipoles: matter’s magnetism by the roll.
- Speakers’ permanent magnets — strong dipole moments (neodymium) facing coil moments: sound from dipole-dipole interplay.
- Magnetic credit-card strips and hard drives — data written as oriented microscopic dipoles: information storage by alignment.
- Magnetic therapy bands and MRI safety checks — strong dipoles interact dangerously with MRI fields: hospitals screen for embedded moments (pacemakers, implants).
Twist a strip of paper half a turn and glue the ends: you get a Möbius loop with only ONE side. Try to make a one-sided strip with two ends — impossible. Magnetic poles have the same topological stubbornness: they aren’t ‘things’ that could exist separately, but features (like the twist) of circulating currents — and a circulation always has two faces.
Cut a moment-0.2 magnet into 10 slices: each piece carries 0.02 — ten complete dipoles, not ten lone poles. No number of cuts changes the count of poles: always equal N’s and S’s, like a coin that’s always two-sided.
Draw field lines through a magnet: they enter at S, flow inside toward N, exit at N, loop back outside to S. Follow any line forever — it never starts or stops, unlike electric lines that must begin on a charge. The closed-loop picture IS the no-monopole law.
Practice set (answers hidden — try first)
(NEET-level) A 50-turn loop, 20 cm², 1 A: m =
(JEE Main-level) A magnet cut in half along ⊥ to axis gives moments
(NEET-level) Magnetic field lines are
(Concept) A magnetic monopole is
(JEE Main-level) Solenoid 200 turns, 25 cm², 2 A: m =
- poles inseparable: no monopoles found
- m = M·2ℓ = NIA
- loop ≡ magnet (Ampere’s guess, quantum-confirmed)
- field lines closed loops
- moment points S → N
- 🔁 dipole-pair property
- 🔁 moment formulas
- 🔁 loop-magnet equivalence
- 🧠 Chant: ‘cut a magnet, get two magnets’.
- 🧠 Loop law: ‘m = NIA — coils are magnets’.
- 🏠 Daily: card strips store data as aligned dipoles.
- 🏠 Daily: MRI screening exists because implants carry moments.
Quick revision
- A bar magnet has two poles that always come in pairs — cut one, get two magnets, never a lone pole
- Magnetic dipole moment: m = M × 2ℓ (pole strength × length), pointing S → N
- A current loop IS a magnetic dipole: m = NIA — magnets are hidden currents
- Field lines run outside N → S, inside S → N: closed loops, no start or end
- No magnetic monopoles have ever been found — the deepest asymmetry with electricity
